NAME
|
ELECTROLIC
TIN STEEL PLATE
|
|
STANDARD
|
JIS G3303-2002
|
ASTM A623M-2002
|
DIN EN 10203-1991
|
ISO 11949-1995
|
|
STEEL
GRADE
|
SPCC/MR
|
|
HARDNESS
|
T-1
|
T-1 (T49)
|
T50
|
TH50＋SE
|
|
T-2
|
T-2 (T53)
|
T52
|
TH52＋SE
|
|
T-2.5
|
－
|
－
|
TH55＋SE
|
|
T-3
|
T-3 (T57)
|
T57
|
TH57＋SE
|
|
－
|
－
|
－
|
－
|
|
T-4
|
T-4 (T61)
|
T61
|
TH61＋SE
|
|
T-5
|
T-5 (T65)
|
T65
|
TH65＋SE
|
|
－
|
DR-7.5
|
－
|
－
|
|
DR-8
|
DR-8
|
DR 550
|
T550＋SE
|
|
－
|
DR-8.5
|
－
|
T580＋SE
|
|
DR-9
|
DR-9
|
DR 620
|
T620＋SE
|
|
DR-9M
|
DR-9.5
|
DR 660
|
T660＋SE
|
SIZE:
|
WIDTH（mm）
|
330 – 1100
|
|
THICKNESS(mm)
|
0.12 – 0.8
|
|
COIL
ID (mm)
|
508/610
|
Surface Finish Type:
|
SURFACE FINISH
|
B
|
Bright Finish
|
A luster surface provided
by a flow-brightened tin coating on a smoothly grindstone finished steel base.
|
|
R
|
Stone Finish
|
A luster surface provided
by a flow-brightened tin coating on a steel base characterized by a directional
grindstone pattern.
|
|
S
|
Silver Finish
|
A luster surface provided
by a flow-brightened tin coating on a coarse dull finish steel base.
|
|
M
|
Matte Finish
|
A dull surface provided by
an unmelted coating generally on dull finished steel base.
|
Tin Coating Weight:
|
COATING
CLASSIFICATION
|
NOMINAL TIN COATING
WEIGHT(g/m2)
|
MIN AVERAGE TIN
COATING WEIGHT(g/m2)
|
|
EQUAL TIN
COATING (E)
|
1.1/1.1
|
0.9/0.9
|
|
2.2/2.2
|
2.0/2.0
|
|
2.8/2.8
|
2.5/2.5
|
|
5.6/5.6
|
5.3/5.3
|
|
DIFFERENTIAL TIN
COATING (D or A)
|
2.2/1.1
|
2.0/0.9
|
|
2.8/1.1
|
2.25/0.9
|
|
5.6/1.1
|
5.05/0.9
|
|
2.8/2.2
|
2.25/2.0
|
|
5.6/2.2
|
5.05/2.0
|
|
5.6/2.8
|
5.05/2.25
|
